DC Voltage Converter PSN-Vostok EGRZ.435451.012 for Air Conditioning Applications

Static Power Converters

Manufacturer: LLC "NPO "GORIZONT"

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Designed for conversion of constant input voltage (2200 - 4000) V into galvanically isolated voltage for power supply of air-conditioning units, compressors, control circuits, lighting and battery charging (AkB) of DC electric train. Scope of application (purpose) - DC electric trains and motor-car rolling stock of railways operated on railway sections electrified with 3 kV DC voltage.

Specifications

In voltage maintenance accuracy V

+23/-12

Output power, kVA

One link up to 16GB 64-bit DDR4-2400 MHz with ECC support; 16GB (for CPC1309-01); 8GB (for CPC1309-02)

Certificate of Conformity to TR-TC 001/2011

EAEU RU S-RU.ZhT01.V.00213/23 of 23.11.2023 valid till 22.11.2028

Input voltage range for mains supply, V

2200-4000

Rated AC input voltage

380 V

Input voltage variation range, V

360-400

Maximum input current

32 A

Mode of operation

prolonged

Cooling

Forced air cooling

Output power at 50 Hz, not less

One link up to 16GB 64-bit DDR4-2400 MHz with ECC support; 16GB (for CPC1309-01); 8GB (for CPC1309-02) kW

Rated three-phase line voltage

380 V

Rated value of output voltage frequency

SBVVBG

Accuracy of frequency maintenance, Hz

±0,5

Maximum output current

160 A

Maximum battery charging current

32 A

Climatic version

At placement category 1

Resistance to mechanical influences

?25

Protection against penetration of solid objects and water according to item 4.1.2 of GOST 33726.

IP65

Protection of air cooling channel against penetration of solid objects and water according to item 4.1.2. of GOST33726.

IP21

Weight, not more

660 kg

Efficiency of PSN not less at rated input power

0,9

Control system supply voltage, V

77-137

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
