Cylindrical horizontal two-stage gearbox 1Ts2U(Ts2U)-100, 1Ts2U(Ts2U)-125, 1Ts2U(Ts2U)-160, 1Ts2U(Ts2U)-200, 1Ts2U(Ts2U)-250

Cylindrical two-stage horizontal gearboxes of general machine-building application of types
1Ts2U(Ts2U)-100, 1Ts2U(Ts2U)-125, 1Ts2U(Ts2U)-200, 1Ts2U(Ts2U)-250 are designed for increasing the torque and decreasing the frequency of speed.
torque and reducing speed.
Conditions of application:
constant and alternating load of one direction and reversible;
continuous operation or with periodic stops;
shaft rotation in any direction;
input shaft speed should not exceed 1800 rpm;
atmosphere of types I and II according to GOST 15150-69 with air dustiness not more than 10 mg/m3;
climatic versions U, T ( for categories of placement 1...3 ) and climatic versions UHL and
O ( for categories of placement 4) according to GOST 15150-69.
Unit designation
1Ts2U-200-10-10-12Ts-U1, where
1Ts2U - type,
200 - centre-to-centre distance,
10 - gear ratio,
12C - assembly variant,
Ts - cylindrical end of output shaft (P - hollow output shaft, M - end of output shaft in the form of a part of a gear coupling).
part of gear coupling)
U1 - climatic....
