Copper Power Cable K9RV with EPR Insulation and PVC Armoring

Available for Import

Copper Power Cable K9RV with EPR Insulation for Electrical Energy Distribution

Copper Power Cables 1kV

Manufacturer:UGLICHKABEL LLC

Price:Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Power cable with insulation made of high-modular ethylene propylene rubber, designed for transmission and distribution of electrical energy in stationary installations for rated alternating voltage 0,6/1 rated frequency up to 50 Hz. The cable is manufactured for general industrial application and is intended for stationary laying in the air, in closed rooms, in the ground, in cable collectors in group laying, including in explosion hazardous zones when supplied to the domestic market and for export, including countries with tropical climate. Types of climatic execution of cables - UHL, XL and T.

Specifications

Rated AC voltage

1 kV

Material of conductive cores

Copper

Insulation material of conductive cores

High modulus ethylene propylene rubber (HEPR)

Availability of reservations

Armoured glass

Armor type

Armor made of aluminum or aluminum alloy wires (AK); Armor made of round galvanized steel wires (SK); Armor made of aluminum or aluminum alloy bands (AB); Armor made of galvanized steel bands (SB)

Outer sheath material (if no armor)

Polyvinylchloride plastic with reduced fire hazard and low smoke and gas emission (PVC LS / PVC LS)

Material of protective hose (if armor is available)

Polyvinylchloride plastic with reduced fire hazard and low smoke and gas emission (PVC LS / PVC LS)

Availability of metal screen

Fire hazard class

P1b.1.2.2.2.2.

Cable cross-sectional shape

Round

Design of conductor core(s)

Single-wire round (ok); multiwire round (mc); multiwire sector (ms)

Nominal cross-section of conductive cores

1000 mm²

Number of conductive cores

1...5

Mark

K9RVSBVng(A)-FRLS(180); K9RVSKVng(A)-FRLS(180); K9RVABVng(A)-FRLS(180); K9RVAKVng(A)-FRLS(180); K9RVSKBVng(A)-FRLS(180)

Cable shape

Round

Core material

Copper

Insulation material

High modulus ethylene propylene rubber (HEPR)

Sheath material

Polyvinylchloride plastic with reduced fire hazard and low smoke and gas emission (PVC LS / PVC LS)

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
