Climate Control System for Electric Train Passenger Cabin AVMYU.667438.062 - Efficient Microclimate Management
Manufacturer:
ATK CJSC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
Cabin microclimate system is designed for operation in electric trains (hereinafter referred to as the Product or COM) of EG, EP, EM types, carrying passengers with a design speed of up to 200 km/h
Specifications
Type of product according to PP RF 616
Industrial climate equipment
Mains 3000 V, DC
Not more than 30 kW
Mains 110 V, dc.
Not more than 2 kW
Mains 380 V, 50 Hz
Not more than 33 kW
Parameter value at outside air temperature tn, ? below 10
20...24 °C
Parameter value at outdoor air temperature tn, ? from 10 to 20
20...24 °C
Parameter value at outdoor air temperature tn, ? from 20 to 40
22+0,2(tn1) -20) 2
At outdoor air temperature tn, ? from 20 to 40
No more than 70
At outside air temperature tn, C below 10 C
30...70 %
At outside air temperature tn, ? from 10 to 20
30...70 %
Air temperature difference at the height of 1500/150 mm , not more
3 °C
Air temperature difference horizontally (across the cabin width) at a height of 1500 mm from the floor, not more than
2 °C
Difference between enclosure temperature and air temperature at 150 mm from the enclosure, C, not more than 32)
3 °C
Air temperature difference horizontally (along the length of the cabin), C, not more than
3 °C
Floor temperature, C, not less
10 °C
Wall temperature, C, not less
15 °C
Below 10
14...18 °C
From 10 to 20
16...24 °C
From 20 to 40
Not more than 28
Air temperature difference at a height of 1500/150 mm, C, max.
3 °C
Air temperature difference (across the cabin width) at a height of 1500 mm from the floor, C, not more than 32)
2 °C
Difference between the enclosure temperature and the air temperature at 150 mm from the enclosure, C, max.
3 °C
Wall temperature, C, not less
10 °C
Parameter value at outdoor air temperature tn, ? below 10 ?
30...70 %
Parameter value at outdoor air temperature tn, ? from 10 to 20
30...70 %
Parameter value at outdoor air temperature tn, ? from 20 to 40
No more than 70
Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
