Atmospheric Cutter A170-0.2 - Ideal for Food Processing Applications
Manufacturer:
INDUSTRIAL PRODUCTION LLC
Price:
Request Quote
Bulk pricing available
FOB, CIF & EXW terms available
Description
Atmospheric (open) cutter A170-0,2 with a bowl volume of 200 litres, made of food-grade stainless steel.
The cutter is equipped with:
- electrical components manufactured by "Schneider Electric";
- Hyundai frequency converter;
- stainless steel bowl with geometry similar to KRÄMER+GREBE cutter bowls;
- knife packages with balanced plates similar in design and execution to KRÄMER+GREBE plates, which guarantees that the knife reach does not increase during the operation of the cutter at high speed of the knife shaft and considerably reduces the time of package assembly.
- SKF bearings;
- automatic water dosing system (optional);
- automatic centralised lubrication of the knife shaft bearings (optional);
- possibility of smooth speed adjustment of the unloader disc in the range from 50 to 120 rpm (optional);
- control system of the cutter....
The cutter is equipped with:
- electrical components manufactured by "Schneider Electric";
- Hyundai frequency converter;
- stainless steel bowl with geometry similar to KRÄMER+GREBE cutter bowls;
- knife packages with balanced plates similar in design and execution to KRÄMER+GREBE plates, which guarantees that the knife reach does not increase during the operation of the cutter at high speed of the knife shaft and considerably reduces the time of package assembly.
- SKF bearings;
- automatic water dosing system (optional);
- automatic centralised lubrication of the knife shaft bearings (optional);
- possibility of smooth speed adjustment of the unloader disc in the range from 50 to 120 rpm (optional);
- control system of the cutter....
Specifications
Geometric volume of the bowl
200 l
Raw material loading
150 kg
Knife shaft speed (reverse)
250
Installed capacity not more than
89 kW
Knife shaft speed min
SBVVBG
Knife shaft speed max
3600
Bowl speed from
8
Bowl speed up to
16
